The TP-Link RE315 is an AC1200 plug-in WiFi range extender that sets up in about five minutes through the Tether app, a browser at tplinkrepeater.net, or the WPS button. This manual covers all three setup methods, the login page and default IP address, how to change the network name and password, Access Point mode (the RE315 version of bridge mode), the LED lights, a factory reset, and fixes for the problems people actually hit with this unit.

Key Takeaways

• The RE315 has no preset admin password. You create one the first time you open http://tplinkrepeater.net or http://192.168.0.254 during setup.
• Its default network name before setup is TP-Link_Extender and its default IP is 192.168.0.254. Once it joins your router, the router assigns it a new IP, which is why tplinkrepeater.net is the reliable way in afterward.
• A solid white signal light means the extender is well placed. Solid red means it is too far from the router. Move it closer until the light turns white.
• Reset is a one-second press of the Reset pin, not a ten-second hold. Holding longer does no harm, but you do not need to.

Affiliate disclosure: ModemGuides may earn a commission on qualifying purchases made through links on this page, at no extra cost to you.

What the TP-Link RE315 Is

The TP-Link RE315 is a dual-band 802.11ac extender that plugs straight into a wall outlet and rebroadcasts your existing WiFi into rooms the router cannot reach. It delivers up to 867 Mbps on 5 GHz and 300 Mbps on 2.4 GHz, adds roughly 1,500 square feet of coverage, and comfortably handles 25 to 30 connected devices.

It is OneMesh and EasyMesh compatible. Paired with a supporting TP-Link router (or any EasyMesh router), it joins the router's network under one WiFi name so phones and laptops roam without switching networks by hand. A single 10/100 Ethernet port on the bottom lets you hard-wire one device such as a TV or console, or run the unit as a wired access point.

TP-Link sells the RE315 in the US as hardware version V1 (labeled V1 or V1.8 on the sticker; both use the same firmware and the same menus). Everything in this manual applies to either.

Key Features

• Dual-band AC1200 speeds: 867 Mbps on 5 GHz plus 300 Mbps on 2.4 GHz.
• Two adjustable external antennas: Fold them up for a stronger, more stable link to the router.
• Fast Ethernet port: Wire one device, or switch the unit to Access Point mode.
• OneMesh and EasyMesh: One network name and automatic roaming with a compatible router.
• WPS button: Pair with the router without typing a password.
• Signal light: Tells you at a glance whether the outlet you picked is a good one.
• Two modes: Range Extender (repeat a wireless signal) or Access Point (turn a wired connection into WiFi).

Specifications at a Glance

What Is in the Box

• TP-Link RE315 WiFi range extender
• Quick Installation Guide

No Ethernet cable or power adapter is included. The unit plugs directly into a standard outlet, and you only need an Ethernet cable if you plan to use the wired port or Access Point mode.

How to Set Up the TP-Link RE315

Pick one of the three methods below. The Tether app is easiest for most people, the browser method gives the most control, and WPS is fastest if your router has a WPS button. Whichever you choose, do the setup with the extender plugged in near your router; you will move it afterward.

Before you start: Plug the RE315 into an outlet in the same room as the router and wait for the Power light to go solid. Have your router's WiFi name and password ready.

Method 1: Tether App (Recommended)

1. Install the free TP-Link Tether app from the App Store or Google Play.
2. Open it and sign in with a TP-Link ID, or create one.
3. Tap the plus icon, choose Range Extender, and pick the RE315.
4. Follow the prompts. The app connects your phone to the extender's TP-Link_Extender network, then asks which of your router's networks to extend and for the router's WiFi password.
5. Create a local admin password for the extender when asked, then finish.

Method 2: Web Browser

1. On a phone or laptop, open WiFi settings and connect to TP-Link_Extender.
2. Open a browser and go to http://tplinkrepeater.net (or http://192.168.0.254).
3. Create an admin password. This protects the extender's settings and is separate from any WiFi password.
4. Select your router's 2.4 GHz network and enter its WiFi password. This is the router's password, not the admin password you just made.
5. Select your router's 5 GHz network and enter its password.
6. Confirm or rename the extended networks, then finish. The extender applies the settings and reconnects.

Method 3: WPS Button

1. Press the WPS button on your router.
2. Within two minutes, press the WPS button on the RE315 for about one second. The signal light starts blinking.
3. Wait for the signal light and the 2.4 GHz and 5 GHz lights to turn solid white. That confirms the pairing.
4. If only one band light comes on, repeat the two button presses to connect the second band.

Note: WPS only works when both the router and the extender have a physical WPS button, and some ISP gateways ship with WPS disabled. If the light never goes solid, use Method 1 or 2 instead.

Find the Best Location After Setup

Once connected, unplug the extender and move it about halfway between the router and the dead zone. It has to stay within good range of the router: an extender in the dead zone repeats a weak signal and produces a weak network. Give it about two minutes to settle, then read the signal light.

• Solid white: Good spot. Leave it.
• Solid red: Too far from the router. Try the next outlet closer.

Keep it out of closed cabinets and away from microwaves, cordless phones, baby monitors, and large metal objects, and angle both antennas upright.

Understanding the LED Lights

The RE315 has four lights on the front: Power, Signal, 2.4 GHz, and 5 GHz. The Signal light is the one that matters for placement.

How to Log In to the RE315 Settings Page

You can open the RE315's management page any time to change settings.

1. Connect your phone or computer to the extender's WiFi, or to the same router the extender is connected to.
2. Open a browser and enter http://tplinkrepeater.net.
3. If that address does not load, try http://192.168.0.254.
4. Log in with the admin password you created during setup, or with your TP-Link ID if you bound the extender to one in Tether.

Neither address opens? Once the extender has joined your router, the router hands it a new IP from its own range and 192.168.0.254 stops working. Open your router's DHCP client list, find the entry named RE315, and enter that IP in your browser. If you cannot find it, reset the extender and use 192.168.0.254 again.

How to Change the WiFi Name (SSID)

1. Log in at http://tplinkrepeater.net.
2. Go to Settings > Wireless > Extended Network.
3. Enter a new name in the 2.4 GHz field, the 5 GHz field, or both.
4. Click Save. Devices will need to rejoin the renamed network.

If you would rather the extender copy your router's network name exactly, turn on the option to use the same SSID as the host network. On a OneMesh or EasyMesh setup, that is automatic.

How to Change the WiFi Password

The RE315 has two passwords that people mix up. The extended network password is what devices use to join the extender's WiFi. The admin password is what you use to log in to the settings page. Change the one that matches your goal.

Change the Extended Network Password

1. Log in at http://tplinkrepeater.net.
2. Go to Settings > Wireless > Extended Network.
3. Enter a new password for the 2.4 GHz and 5 GHz networks.
4. Click Save and reconnect your devices.

By default the extended network uses the same password as your router. If you want them to stay matched, leave it set to copy the host network.

Change the Admin (Login) Password

1. Log in at http://tplinkrepeater.net.
2. Go to Settings > System Tools > Admin Account.
3. Enter the current password, then the new one twice.
4. Click Save.

How to Set Up Access Point (Bridge) Mode

There is no menu item on the RE315 labeled bridge mode. Its default Range Extender mode already works as a wireless bridge that repeats your existing WiFi. If instead you have a wired internet source (an Ethernet wall jack, a switch, or a router with no WiFi) and want to turn it into WiFi, use Access Point mode. That is the RE315 equivalent of bridge mode.

1. Run an Ethernet cable from the wired source to the port on the bottom of the RE315.
2. Log in at http://tplinkrepeater.net.
3. Open the Mode menu at the top of the page and choose Access Point.
4. The extender restarts. Follow the prompts to name the new WiFi network and set its password.
5. Reconnect your devices to the new network.

To go back to repeating a wireless signal, switch the Mode menu to Range Extender. Keep in mind the wired port is 10/100, so Access Point mode tops out at about 100 Mbps regardless of your plan.

How to Update the Firmware

1. Log in at http://tplinkrepeater.net.
2. Go to Settings > System Tools > Firmware Upgrade.
3. Click Check for Upgrade and follow the prompts. The Tether app can do the same from its settings screen.
4. Do not unplug the extender while it updates. It restarts on its own when done.

How to Reset the RE315 to Factory Defaults

A reset wipes every setting and returns the extender to its out-of-the-box state. Use it if you forgot the admin password, cannot reach the login page, or setup is stuck.

1. With the extender plugged in and powered, find the recessed Reset button.
2. Press it with a pin or paperclip for about one second, then let go. The lights blink and the unit reboots.
3. Wait about a minute. It comes back as TP-Link_Extender at 192.168.0.254.
4. Run setup again using any of the three methods above.

If you can still log in, Settings > System Tools > Backup & Restore > Factory Restore does the same thing from the browser.

Troubleshooting Common Issues

tplinkrepeater.net will not open

• Make sure you are connected to the extender's WiFi (TP-Link_Extender if it has not been set up yet).
• Type the address with no www and no extra spaces, or use http://192.168.0.254.
• Turn off mobile data on your phone so the request does not bypass the extender.
• Try a different browser or a private window.
• If the extender is already on your router, look up its current IP in the router's DHCP client list and use that.

Signal light is red

• The extender is too far from the router. Move it to an outlet closer to the halfway point until the light turns white.
• Get it out from behind furniture and away from microwaves and cordless phones.
• Point both antennas straight up.

Extender connects but internet is slow

• Move it closer to the router. A weak link to the router caps the speed it can pass along.
• Put demanding devices on the 5 GHz extended network. It is faster at short range.
• Check that devices are actually joining the extended network and not clinging to the router's weaker signal.
• Update the firmware, then restart the extender.
• Expect some loss. A repeater gives up throughput by design. If you need full speed in the far room, a mesh system holds speed far better than any plug-in extender.

WPS setup fails

• Press the router's WPS button first, then the extender's within two minutes.
• Many ISP gateways ship with WPS turned off. Use the Tether app or browser method instead.
• Keep the extender within a few feet of the router during pairing, then relocate it.

Devices will not connect to the extended network

• Confirm the password. By default it matches your router's WiFi password.
• Forget the network on the device, then rejoin.
• Unplug the extender for ten seconds and plug it back in.

Forgot the admin password

• There is no recovery option. Reset the extender and create a new admin password during setup.

Access Point mode has no internet

• Reseat the Ethernet cable at both ends and try a different cable.
• If you are using an in-wall run, test the extender plugged straight into the router first to rule out the wall wiring.
• Confirm the Mode menu is set to Access Point, not Range Extender.

Frequently Asked Questions

What is the default login for the TP-Link RE315?

There is no preset password. Connect to the extender, open http://tplinkrepeater.net or http://192.168.0.254, and create your own admin password the first time you log in.

What is the IP address of the RE315?

192.168.0.254 out of the box. After it joins your router, the router assigns a new IP; check the router's DHCP client list or just use tplinkrepeater.net.

Does the RE315 create a separate WiFi network?

By default it broadcasts its own extended network name (usually your router's name with _EXT added). You can set it to use the same name as the router, and on a OneMesh or EasyMesh setup it does that automatically.

Can the RE315 work as an access point?

Yes. Connect it to a wired router or Ethernet jack, then switch the Mode menu to Access Point. That turns the wired connection into a WiFi network and is the RE315's version of bridge mode.

How far can the RE315 extend my WiFi?

Roughly 1,500 square feet of added coverage and about 25 to 30 devices. Walls, interference, and how strong the router's signal is at the outlet all change the real-world number.

RE315 vs RE220 vs RE305: what is the difference?

All three are AC1200 plug-in extenders. The RE315 adds two external antennas and OneMesh and EasyMesh support, which the RE220 lacks. The RE305 has the same antennas but no mesh support. If your router is a recent TP-Link Archer or any EasyMesh router, the RE315 is the one to get; otherwise they perform about the same.

How do I reset the RE315 if I forgot my password?

Press the Reset pin for about one second while the unit is powered on. It reboots to factory defaults so you can set a new admin password during setup.
